Python Programming
for big Data Analysis and Visualisation

Session 5 : Data Exploration

Welcome to Session 5 of the Python Programming for big Data Analysis and Visualisation course. In this notebook you will find the material covered during this session.

Exercises

There are 2 exercises and 1 mini-project in this notebook.

• Exercise 1
• Exercise 2
• Exercise 3
• Exercise 4
• Exercise 5
• Project: Tips

Recap: visualisation

Last time we saw how to make the most common plots using pyplot, pandas and seaborn. In particular we saw:

• Scatterplots to study the relationship between two variables (typically continuous):
  • plt.scatter();
  • pd.DataFrame.plot.scatter();
  • sns.scatterplot() (and sns.swarmplot if one variable is categorical).
• Lineplots as the most basic type of plot, using the very powerful plt.plot.
• Barplots to study the relationship between a categorical and a continuous variable:
  • pd.DataFrame.plot.bar() and pd.Series.plot.bar();
• Histograms to study the distribution of a variable (typically continuous):
  • plt.hist();
  • pd.DataFrame.hist();
  • sns.histplot() for continuous variables;
  • sns.countplot() for categorical variables.
• Boxplots to study the relationship between a categorical and a continuous variable:
  • pd.DataFrame.boxplot();
  • sns.boxplot() and sns.violinplot().

All of these libraries use matplotlib in the background, so we can use common pyplot commands to enrich our representations: plt.xlabel(), plt.ylabel(), plt.xlim(), plt.ylim(), plt.grid(), plt.title(), etc...

We also saw two common ways to manipulate your DataFrames:

• Sorting is an important operation we do on continuous variables: for example titanic.sort_values('age') and titanic.sort_index().
• Split-apply-combine to group rows of your data according to the value of a categorical variable, in order to manipulate each group separately: for example titanic.groupby('sex').mean() (see also other methods specified above).

More pandas

We will see three more fundamental pandas techniques :

1. Working with missing data;
2. Renaming columns;
3. Changing column types.

# first let's import some libraries
import pandas as pd
import matplotlib.pyplot as plt
import seaborn as sns

Working with missing data

Working with missing data is very common. A typical example of missing data could be a csv-formatted data file like the following:

name,sex,age,fare,survived
Allen,male,,8.05,0
...

(the age of M. Allen is missing).

Missing data in pandas is represented by the numpy.NaN value, which is of type float.

Checking if data is missing can be done using pd.DataFrame.isna() and pd.Series.isna().
Missing data can be removed from a DataFrame by using pd.DataFrame.dropna(); note that the options axis, how and subset of pd.DataFrame.dropna() (see examples below and the help) can help with only removing the problematic missing data.

Let's load a modified version of the titanic dataset that contains few rows with some missing data :

titanic = pd.read_csv("https://marcopasi.github.io/physenbio_pyDAV/data/titanic_na.csv", index_col=0)

titanic.info()  # .info informs us on null (missing) data

<class 'pandas.core.frame.DataFrame'>
Index: 10 entries, Allen to Vestrom
Data columns (total 4 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   sex       9 non-null      object
 1   age       8 non-null      float64
 2   fare      9 non-null      float64
 3   survived  10 non-null     int64
dtypes: float64(2), int64(1), object(1)
memory usage: 400.0+ bytes

titanic.isna()

	sex	age	fare	survived
name
Allen	False	True	False	False
Braund	False	False	False	False
Cumings	True	False	False	False
Futrelle	False	True	True	False
Futrelle	False	False	False	False
Heikkinen	False	False	False	False
Jussila	False	False	False	False
Madsen	False	False	False	False
Sloper	False	False	False	False
Vestrom	False	False	False	False

titanic.dropna()

	sex	age	fare	survived
name
Braund	male	22.0	7.25	0
Futrelle	male	37.0	53.10	0
Heikkinen	female	26.0	7.92	1
Jussila	female	20.0	9.82	0
Madsen	male	24.0	7.14	1
Sloper	male	28.0	35.50	1
Vestrom	female	14.0	7.85	0

titanic.dropna(axis='columns')

	survived
name
Allen	0
Braund	0
Cumings	1
Futrelle	1
Futrelle	0
Heikkinen	1
Jussila	0
Madsen	1
Sloper	1
Vestrom	0

Exercise 1

Load the full titanic dataset from "https://marcopasi.github.io/physenbio_pyDAV/data/titanic.csv", using the first column as index. Then:

1. Create a new dataframe by removing rows with NA values: how many lines were removed?
2. Create a new dataframe by removing columns with NA values: how many columns were removed? How many lines are left?

titanic = pd.read_csv("https://marcopasi.github.io/physenbio_pyDAV/data/titanic.csv").set_index("name")

titanic1 = titanic.dropna()
len(titanic) - len(titanic1)

708

titanic2 = titanic.dropna(axis="columns")
print(len(titanic.columns) - len(titanic2.columns))
len(titanic2)

3

891

titanic.dropna(subset=["age"])

	sex	age	fare	survived
name
Braund	male	22.0	7.25	0
Cumings	NaN	38.0	71.28	1
Futrelle	male	37.0	53.10	0
Heikkinen	female	26.0	7.92	1
Jussila	female	20.0	9.82	0
Madsen	male	24.0	7.14	1
Sloper	male	28.0	35.50	1
Vestrom	female	14.0	7.85	0

Renaming columns

We've seen modifying the DataFrame index using pd.DataFrame.set_index() and pd.DataFrame.reset_index(); but what about modifying column labels? We can use pd.DataFrame.rename(). The columns argument is a dict, where each key is a column name to rename, and each value is the new name: simple and expressive.

# rename column age to Age
titanic.rename(columns={"age": "Age"})

	sex	Age	fare	survived
name
Allen	male	NaN	8.05	0
Braund	male	22.0	7.25	0
Cumings	NaN	38.0	71.28	1
Futrelle	female	NaN	NaN	1
Futrelle	male	37.0	53.10	0
Heikkinen	female	26.0	7.92	1
Jussila	female	20.0	9.82	0
Madsen	male	24.0	7.14	1
Sloper	male	28.0	35.50	1
Vestrom	female	14.0	7.85	0

Changing column types

We've seen that pd.DataFrame.info() informs us on the type of each column of a DataFrame, initially determined automatically by pd.read_csv(). It may sometimes be useful to change the type to something more appropriate: we can use pd.DataFrame.astype(). The argument to astype is a dict, where each key is a column name, and each value is the desired type for that column (similar to the columns argument of pd.DataFrame.rename() !).

titanic.dropna().astype({"age": int, "survived": bool, "sex": "category"})

	sex	age	fare	survived
name
Braund	male	22	7.25	False
Futrelle	male	37	53.10	False
Heikkinen	female	26	7.92	True
Jussila	female	20	9.82	False
Madsen	male	24	7.14	True
Sloper	male	28	35.50	True
Vestrom	female	14	7.85	False

Remember: method chaining (i.e. pd.DataFrame.first_operation().second_operation().third_operation()) is an expressive and concise way to perform multiple operations on a DataFrame !

Exercise 2

Load the full titanic dataset from "https://marcopasi.github.io/physenbio_pyDAV/data/titanic.csv", using the first column as index.
Perform the following operations in a chain :

1. rename the column pclass to "ticket_class";
2. remove rows with any NA values at the age column;
3. set the type of age to int, of survived to bool and of ticket_class to category.

titanic = pd.read_csv("https://marcopasi.github.io/physenbio_pyDAV/data/titanic.csv").set_index("name")

titanic = titanic \
    .rename(columns={"pclass": "ticket_class"}) \
    .dropna(subset=["age"]) \
    .astype({"age": int, "survived": bool, "ticket_class": "category"})
titanic.head()

	passengerId	survived	ticket_class	sex	age	sibsp	parch	ticket	fare	cabin	embarked
name
Braund, Mr. Owen Harris	1	False	3	male	22	1	0	A/5 21171	7.2500	NaN	S
Cumings, Mrs. John Bradley (Florence Briggs Thayer)	2	True	1	female	38	1	0	PC 17599	71.2833	C85	C
Heikkinen, Miss. Laina	3	True	3	female	26	0	0	STON/O2. 3101282	7.9250	NaN	S
Futrelle, Mrs. Jacques Heath (Lily May Peel)	4	True	1	female	35	1	0	113803	53.1000	C123	S
Allen, Mr. William Henry	5	False	3	male	35	0	0	373450	8.0500	NaN	S

Data Exploration

Exploratory Data Analysis (EDA) is a set of techniques and approaches aimed at analyzing data sets to summarize their main characteristics. It is a fundamental step towards using the data to train a predictive model (e.g. in machine learning) and to make hypotheses about the phenomena described in the data.

EDA has two main goals:

1. Determine whether the data makes sense and is ready for analysis, or it needs further cleaning/manipulation;
2. Find relevant patterns and trends in the data.

We will split EDA in 4 phases:

1. Initial exploration
2. Monovariate analysis
3. Bivariate analysis
4. Multivariate analysis

Initial exploration

Tries to answer the following questions:

1. Has the data been loaded correctly?
   Do we need to rename columns or set an index?
2. Is the dataset complete or does it contain missing data?
   Do we need to drop NAs?
3. What are the variables and their types?
   Have the variable types been guessed correctly by pd.read_csv?

titanic = pd.read_csv("https://marcopasi.github.io/physenbio_pyDAV/data/titanic.csv").set_index("name")
titanic.head()
titanic.info()

<class 'pandas.core.frame.DataFrame'>
Index: 891 entries, Braund, Mr. Owen Harris to Dooley, Mr. Patrick
Data columns (total 11 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   passengerId  891 non-null    int64
 1   survived     891 non-null    int64
 2   pclass       891 non-null    int64
 3   sex          891 non-null    object
 4   age          714 non-null    float64
 5   sibsp        891 non-null    int64
 6   parch        891 non-null    int64
 7   ticket       891 non-null    object
 8   fare         891 non-null    float64
 9   cabin        204 non-null    object
 10  embarked     889 non-null    object
dtypes: float64(2), int64(5), object(4)
memory usage: 83.5+ KB

titanic = titanic\
    .dropna(subset=["age", "embarked"]) \
    .rename(columns={"pclass": "ticket_class"})\
    .astype({"survived": bool, "ticket_class": "category",
             "age": int, "sex": "category", "embarked": "category"})

Monovariate analysis

Obtain descriptive statistics of each numerical variable using pd.DataFrame.describe().

Visual inspection of each variable according to its type:

• continuous: sns.histplot() (note option kde=True)
• categorical: sns.countplot()

titanic.describe()

	passengerId	age	sibsp	parch	fare
count	712.000000	712.000000	712.000000	712.000000	712.000000
mean	448.589888	29.622191	0.514045	0.432584	34.567251
std	258.683191	14.502891	0.930692	0.854181	52.938648
min	1.000000	0.000000	0.000000	0.000000	0.000000
25%	222.750000	20.000000	0.000000	0.000000	8.050000
50%	445.000000	28.000000	0.000000	0.000000	15.645850
75%	677.250000	38.000000	1.000000	1.000000	33.000000
max	891.000000	80.000000	5.000000	6.000000	512.329200

titanic.describe(include="all")

	passengerId	survived	ticket_class	sex	age	sibsp	parch	ticket	fare	cabin	embarked
count	712.000000	712	712.0	712	712.000000	712.000000	712.000000	712	712.000000	183	712
unique	NaN	2	3.0	2	NaN	NaN	NaN	541	NaN	133	3
top	NaN	False	3.0	male	NaN	NaN	NaN	347082	NaN	G6	S
freq	NaN	424	355.0	453	NaN	NaN	NaN	7	NaN	4	554
mean	448.589888	NaN	NaN	NaN	29.622191	0.514045	0.432584	NaN	34.567251	NaN	NaN
std	258.683191	NaN	NaN	NaN	14.502891	0.930692	0.854181	NaN	52.938648	NaN	NaN
min	1.000000	NaN	NaN	NaN	0.000000	0.000000	0.000000	NaN	0.000000	NaN	NaN
25%	222.750000	NaN	NaN	NaN	20.000000	0.000000	0.000000	NaN	8.050000	NaN	NaN
50%	445.000000	NaN	NaN	NaN	28.000000	0.000000	0.000000	NaN	15.645850	NaN	NaN
75%	677.250000	NaN	NaN	NaN	38.000000	1.000000	1.000000	NaN	33.000000	NaN	NaN
max	891.000000	NaN	NaN	NaN	80.000000	5.000000	6.000000	NaN	512.329200	NaN	NaN

# Categorical : countplot
plt.subplot(2,2,1)
sns.countplot(x="survived", data=titanic)
plt.subplot(2,2,2)
sns.countplot(x="ticket_class", data=titanic)
plt.subplot(2,2,3)
sns.countplot(x="sibsp", data=titanic)
plt.subplot(2,2,4)
sns.countplot(x="parch", data=titanic)
plt.tight_layout()

# Continuous : histplot
plt.figure(figsize=(10,4))
plt.subplot(2,2,1)
sns.histplot(x="age", data=titanic)
plt.subplot(2,2,2)
sns.histplot(x="sibsp", data=titanic)
plt.subplot(2,2,3)
sns.histplot(x="parch", data=titanic)
plt.subplot(2,2,4)
sns.histplot(x="fare", data=titanic, kde=True)
plt.tight_layout()

Bivariate analysis

Evaluate the statistical relationships between pairs of numerical variables using pd.DataFrame.corr(). A powerful way to visualise the resulting correlation matrix is using sns.heatmap(); note the option annot makes interpretation easier.

Visual inspection of the relationship between pairs of variables according to their type:

• continuous vs categorical: sns.boxplot() and sns.violinplot()
• continuous vs continuous: sns.jointplot() (note options kind="hex" and kind="kde")
• categorical vs categorical: sns.countplot() (using x=... and hue=...)

Remember to use the option hue to add a further categorical variable.

sns.heatmap(titanic.corr(method='spearman'), annot=True)

<AxesSubplot:>

# Continuous vs categorical : boxplot (or violinplot)
# ... 2 examples:
sns.boxplot(x="survived", y="fare", data=titanic, hue="ticket_class")
plt.figure()
sns.violinplot(x="survived", y="fare", data=titanic, hue="sex", split=True, cut=0)

<Axes: xlabel='survived', ylabel='fare'>

# Continuous vs continuous : jointplot
# ... 2 examples, using the only 2 continuous variables in this dataset
sns.jointplot(x="age", y="fare", data=titanic, hue="sex")
plt.figure()
sns.jointplot(x="age", y="fare", data=titanic, kind="hex")
# The kind=hex option allows us to see where most points are located (2D histogram)

<seaborn.axisgrid.JointGrid at 0x7fa592f84e20>

<Figure size 640x480 with 0 Axes>

# Categorical vs categorical : countplots using x= and hue=
# ... 2 examples
sns.countplot(x="survived", hue="sex", data=titanic)
plt.figure()
sns.countplot(x="ticket_class", hue="sex", data=titanic)

<AxesSubplot:xlabel='ticket_class', ylabel='count'>

Multivariate analysis

Pseudo-multivariate visual inspection of the relationship between multiple variables according to their type. In addition to the use of hue in several cases above, there are two common techniques to extend a plot to take into account further categorical variables:

1. Extend a scatterplot using sns.relplot();
2. Extend a boxplot or countplot using sns.catplot() (remember kind="box" and kind="count" respectively).

Relplots

# Extend the age vs fare scatterplot to consider also sex, survived and pclass : 5 variables in total !!!
sns.relplot(x="age", y="fare", data=titanic, hue="sex", row='survived', col='ticket_class')

<seaborn.axisgrid.FacetGrid at 0x7f8b8f422f70>

Catplots

# Extend the survived vs fare boxplot to consider also sex and pclass
sns.catplot(x="survived", y="fare", data=titanic, hue="sex", kind='box', col='ticket_class')

<seaborn.axisgrid.FacetGrid at 0x7f8b8f5dee50>

# Extend the survived countplot to consider also sex and pclass
sns.catplot(x="survived", data=titanic, hue="sex", kind='count', col='ticket_class')

<seaborn.axisgrid.FacetGrid at 0x7f8bad127160>

Hypothesis testing

Hypothesis testing is one of the workhorses of science: it is how we can draw conclusions or make decisions based on finite samples of data ; in this context, we will be using hypothesis testing to determine whether or not our dataset can provide sufficient evidence to claim that a given null hypothesis is false.

R is a language dedicated to statistics, while Python is a general-purpose language with statistics modules. R has more statistical analysis features than Python, and specialized syntaxes, but Python can still perform some basic hypothesis testing. In particular, we will be using the stats module of the scipy library to perform some basic hypothesis testing.

from scipy import stats

Continuous vs categorical (binary): comparing two means

Many experimental measurements are reported as rational numbers, and the simplest comparison we can make is between two groups: the basic test for such situations is the t-test. The t-test comes in multiple flavors, and the specific type of test to use depends on a variety of factors. Below are listed the scipy.stats functions that perform the test, always returning the t statistic and the p-value.

• one-sample test: ttest_1samp(x, popmean)

the null hypothesis is that the mean of sample x is equal to a given population mean popmean.

• two-sample tests:

the null hypothesis is that samples x1 and x2 have the same mean;

• for independent samples: ttest_ind(x1, x2)
  the test assumes equal variances (homoscedasticity) in the two groups;
  specifying equal_var=False performs Welch's t-test, which relaxes this assumption.
• for paired samples: ttest_rel(x1, x2)

t, p_value = stats.ttest_1samp(titanic.loc[:, "age"], 42.4)

t, p_value = stats.ttest_ind(titanic.set_index("survived").loc[False, "age"],
                             titanic.set_index("survived").loc[True, "age"])

titanic.groupby("survived").var().loc[:, "age"]

survived
False    200.664832
True     221.781601
Name: age, dtype: float64

Exercise 3

Determine if there is a statistically significant association between the age of passengers and their sex.

titanic.groupby("sex").var().loc[:, "age"]

sex
female    196.056658
male      215.736213
Name: age, dtype: float64

t, p_value = stats.ttest_ind(titanic.set_index("sex").loc["male", "age"],
                             titanic.set_index("sex").loc["female", "age"])

Non-parametric tests for comparing two means

All t-tests assume that errors are normally distributed. Non-parametric tests have been developed that relax this assumption. The non-parametric versions of the two-sample tests are very similar to the t-tests, and return the test statistic and the p-value.

• for independent samples: mannwhitneyu(x1, x2)
• for paired samples: wilcoxon(x1, x2)

u, p_value = stats.mannwhitneyu(titanic.set_index("survived").loc[False, "fare"],
                                titanic.set_index("survived").loc[True, "fare"])

Continuous vs categorical: comparing several means

Analysis of variance (ANOVA) is a collection of statistical models that generalise t-tests beyond two means. In particular one-way ANOVA tests the null hypothesis that two or more groups have the same population mean. ANOVA can be performed using stats.f_oneway(s1, s2, s3, ...), returning the test statistic as well as the p-value.

ANOVA has important assumptions that must be satisfied in order for the associated p-value to be valid:

1. The samples are independent.
2. Each sample is from a normally distributed population.
3. The population standard deviations of the groups are all equal (homoscedasticity).

The Kruskal-Wallis H-test is a non-parametric version of ANOVA that relaxes assumptions 2 and 3. The null hypothesis that the population median of all of the groups are equal. The K-W test can be performed using stats.kruskal(s1, s2, s3, ...), returning the test statistic as well as the p-value. For the p-value to be valid, the number of samples in each group must not be too small; a typical rule is that each sample must have at least 5 measurements.

titanic.groupby("ticket_class").var().loc[:, "age"]

ticket_class
1    218.755405
2    196.763880
3    156.028997
Name: age, dtype: float64

f, p_value = stats.f_oneway(titanic.set_index("ticket_class").loc[1, "age"],
                            titanic.set_index("ticket_class").loc[2, "age"],
                            titanic.set_index("ticket_class").loc[3, "age"])

Exercise 4

Determine if there is a statistically significant association between the fare payed by passengers and their ticket_class.

titanic.groupby("ticket_class").var().loc[:, "fare"]

ticket_class
1    6608.637062
2     173.908290
3     100.865030
Name: fare, dtype: float64

h, p_value = stats.kruskal(titanic.set_index("ticket_class").loc[1, "fare"],
                           titanic.set_index("ticket_class").loc[2, "fare"],
                           titanic.set_index("ticket_class").loc[3, "fare"])

Continuous vs continuous: correlation

The statistical relationship between two continuous variables can be quantified by means of a correlation coefficient. It is possible to perform an associated test, where the null hypothesis is that such a coefficient is equal to zero. Below are the methods that perform such tests, and return the calculated coefficient as well as the p-value:

• Pearson's correlation coefficient

is a measure of linear correlation between two sets of data: stats.pearsonr(x, y)

• Spearman's correlation coefficient

is a measure of monotonic correlation between two sets of data: stats.spearmanr(x, y)

r, p_value = stats.spearmanr(titanic.loc[:, "fare"],
                             titanic.loc[:, "age"])

Categorical vs categorical: comparing frequencies

Many measurement devices in biology are based on sampling and counting of molecules. The simplest comparisons we can make involve comparing such counts or frequencies among groups. Count data can often be conveniently stored in contingency tables; the family of $\chi^2$ tests is used in the analysis of contingency tables.

We can calculate contingency tables with pandas, for example using pd.crosstab(series1, series2), or pd.Series.value_counts() for one-dimensional tables.

Below are listed the scipy.stats functions that perform the tests, returning (unless otherwise indicated) the $\chi^2$ statistic and the p-value.

• one-sample test: chisquare(f_obs, f_exp)

the null hypothesis is the the categorical data in (one-dimensional) contingency table f_obs has the same frequencies as in f_exp; by default, f_exp is taken as a uniform distribution.

• two-sample test: chi2_contingency(observed)

the null hypothesis is that observed frequencies in the contingency table observed correspond to independent variables; expected frequencies are computed based on the marginal sums under the assumption of independence. It returns 4 values: $\chi^2$ statistic, p-value, number of degrees of freedom and expected contingency table.

An often quoted guideline for the validity of the two-sample $\chi^2$ test is that the observed and expected frequencies in each cell should be at least 5. Fisher's exact test (or hypergeometric test) is an alternative, equivalent test that relaxes this assumption; it can be performed on a 2x2 contingency table using fisher_exact(observed), returning the odds-ratio and the p-value.

chi2, p_value = stats.chisquare(titanic.loc[:, "sex"].value_counts())

contingency = pd.crosstab(titanic.loc[:, "sex"], titanic.loc[:, "survived"])
contingency

survived	False	True
sex
female	64	195
male	360	93

chi2, p_value, dof, expected = stats.chi2_contingency(contingency)
# odds_ratio, p_value = stats.fisher_exact(contingency)

Exercise 5

Determine if there is a statistically significant association between the ticket_class of passengers and their survival.

contingency = pd.crosstab(titanic.loc[:, "ticket_class"], titanic.loc[:, "survived"])

chi2, p_value, dof, expected = stats.chi2_contingency(contingency)

mini-Project

Tips

Take the Tips dataset from the previous notebook and perform a full EDA analysis using all the techniques described above.

On the basis of the EDA, formulate 3 hypotheses on the underlying phenomenon.

The data is available at the following address:

https://marcopasi.github.io/physenbio_pyDAV/data/tips.csv

Here is a description of the variables:

Variable	Definition	Key
total_bill	Total bill (cost of the meal), including tax, in US dollars
tip	Tip (gratuity) in US dollars
sex	Sex of person paying for the meal	Female, Male
smoker	Smoker in party?	Yes, No
day	Day of the week	Thu, Fri, Sat, Sun
time	Time of day	Lunch, Dinner
size	Size of the party

tips = pd.read_csv("https://marcopasi.github.io/physenbio_pyDAV/data/tips.csv")
_tips = tips

tips.head()

	total_bill	tip	sex	smoker	day	time	size
0	16.99	1.01	Female	No	Sun	Dinner	2
1	10.34	1.66	Male	No	Sun	Dinner	3
2	21.01	3.50	Male	No	Sun	Dinner	3
3	23.68	3.31	Male	No	Sun	Dinner	2
4	24.59	3.61	Female	No	Sun	Dinner	4

tips.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 244 entries, 0 to 243
Data columns (total 7 columns):
 #   Column      Non-Null Count  Dtype
---  ------      --------------  -----
 0   total_bill  244 non-null    float64
 1   tip         244 non-null    float64
 2   sex         244 non-null    object
 3   smoker      244 non-null    object
 4   day         244 non-null    object
 5   time        244 non-null    object
 6   size        244 non-null    int64
dtypes: float64(2), int64(1), object(4)
memory usage: 13.5+ KB

tips = tips.astype({"sex":"category", "smoker":"category", "day":"category", "time":"category"})
tips.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 244 entries, 0 to 243
Data columns (total 7 columns):
 #   Column      Non-Null Count  Dtype
---  ------      --------------  -----
 0   total_bill  244 non-null    float64
 1   tip         244 non-null    float64
 2   sex         244 non-null    category
 3   smoker      244 non-null    category
 4   day         244 non-null    category
 5   time        244 non-null    category
 6   size        244 non-null    int64
dtypes: category(4), float64(2), int64(1)
memory usage: 7.3 KB

tips2.describe()
tips2.describe(include=['category'])

	sex	smoker	day	time
count	244	244	244	244
unique	2	2	4	2
top	Male	No	Sat	Dinner
freq	157	151	87	176

# univariate
plt.subplot(2,2,1)
sns.countplot(x="sex", data=tips)
plt.subplot(2,2,2)
sns.countplot(x="smoker", data=tips)
plt.subplot(2,2,3)
sns.countplot(x="day", data=tips)
plt.subplot(2,2,4)
sns.countplot(x="time", data=tips)
plt.tight_layout()

plt.figure(figsize=(10,6))
plt.subplot(2,2,1)
sns.histplot(x="size", data=tips)
plt.subplot(2,2,2)
sns.histplot(x="total_bill", data=tips, kde=True)
plt.subplot(2,1,2)
sns.histplot(x="tip", data=tips, kde=True)
plt.tight_layout()

# ...

License

This work is licensed under a Creative Commons Attribution-ShareAlike 4.0 International License.
